CS-Rv120-4FL (Coated, 60° x 2)
“Super” carbide, coated, 4-flute, V-cut router bit with a 6mm cutting edge diameter and max milling depth of 1.7mm. Has 4 flutes with 60° angles which creates a 120° v-cut angle.
Description
“Super” carbide, coated, 4-flute, V-cut router bit with a 6mm cutting edge diameter and max milling depth of 1.7mm. Has 4 flutes with 60° angles which creates a 120° v-cut angle.
Additional information
| Machine Model | Colex, Gerber, IECHO, Kongsberg, Multicam, Summa, Zund |
|---|---|
| Process Category | Router bits |
| Process Type | Route – V-Fold |
| Flutes | 4 flutes |
| Cut Angle | 60° x 2 (120°) |
| Routing Diameter | 6 mm |
| Max Rpm | 50000 |
| Max Material Thickness | 1.7 mm |
| Shank Diameter | 6 mm |
| Length Overall | 60 |
| Board – Rigid | ACM, Acrylic, Alucobond, Dibond®, Dilite, E-Panel®, EVA – Ethylene Vinyl Acetate, Expanded PVC, Gatorfoam®, Gatorplast®, HDU – High Density Urethane, IGEPA Bond Premium, IGPA, Komatex®, Max Metal®, Plaskolite®, Polycarbonate Board, Polyethylene 4 lbs., Precision Board®, Reynobond, Sign Foam®, Sintra®, Ultra Board® |
| Metal | Aluminum, ChromaLuxe® HD Aluminum, Hard Brass |
| Wood | Balsa, Birch Plywood, MDF, Poplar |
