CS-K68
60,00 €
 Very robust, heavy-duty oscillating blade for sandwich materials and corrugated plastic and cardboard.
In stock
Description
 Very robust, heavy-duty oscillating blade for sandwich materials and corrugated plastic and cardboard.
Additional information
| Weight | 0,1 kg |
|---|---|
| Machine Model | Gerber, IECHO, Kongsberg, Multicam, Summa, Zund |
| Process Category | Knife blades |
| Process Type | Knife – Oscillate |
| Cut Angle | 83° + 5° |
| Max Material Thickness | 29 mm |
| End Overcut | 1.9 + 0.12 mm |
| Blade Thickness | 1.5 mm |
| Knife Type | Flat Stock |
| Board – Soft | Corrugated Plastic, corrugated sandwich, Dispa®, F-Sorb®, Foam Board, Fome-Cor®, Insite® Foam Board, Matboard, Polyester Acoustic Board, Reboard®, Sandwich Board, Xanita® Board |
| Corrugated Single | A Flute, B Flute, C Flute, D Flute, E Flute, F Flute |
| Corrugated Double Wall | A/B Flute, B/C Flute, B/E Flute, E/B Flute, E/C Flute, E/E Flute, F/E Flute |
| Corrugated Triple Wall | A/B/A Flute, E/B/E Flute |
| Composite | Armid Dry Fiber, Dry Carbon Fiber, Dry Glass Fiber, Nomex® Dry Fiber |
