CS-Rc5415 (Compression)
CS-Rc5415 (Compression) - Image 2
CS-Rc5415 (Compression) - Image 3

CS-Rc5415 (Compression)

82,00 €

Multielement multilayered “rainbow” coated, “Super” carbide, polished, compression (both up and down flute) router bit with a 4mm cutting edge diameter and max milling depth of 14mm. Please note that this bit requires a minimum thickness of 3mm for the compression feature to work.

In stock

SKU: csrc5415
Category: , ,

Description

Multielement multilayered “rainbow” coated, “Super” carbide, polished, compression (both up and down flute) router bit with a 4mm cutting edge diameter and max milling depth of 14mm. Please note that this bit requires a minimum thickness of 3mm for the compression feature to work.

Additional information

Machine Model

Colex, Cosign, Gerber, IECHO, Kongsberg, Multicam, Summa, Zund
Process Category

Router bits
Process Type

Route – Compression
Flutes

2 Flutes
Cut Angle

Compression Cut
Routing Diameter

4 mm
Max Material Thickness

14 mm
Shank Diameter

6 mm
Length Overall

60
Max Rpm

40000
Board – Rigid

ACM, Acrylic, Alucobond, Dibond®, Dilite, E-Panel®, EVA – Ethylene Vinyl Acetate, Expanded PVC, Gatorfoam®, Gatorplast®, HDU – High Density Urethane, IGEPA Bond Premium, IGPA, Komatex®, Max Metal®, Plaskolite®, Polycarbonate Board, Polyethylene 4 lbs., Precision Board®, Reynobond, Sign Foam®, Sintra®, Ultra Board®
Wood

Balsa, Birch Plywood, MDF, Poplar
Material

Board – Rigid, Wood
