CS-Rc5622-A (Compression)
CS-Rc5622-A (Compression) - Image 2

CS-Rc5622-A (Compression)

90,00 €

Multielement multilayered “rainbow” coated, “Super” carbide, polished, compression (both up and down flute) router bit with a 6mm cutting edge diameter and max milling depth of 22mm. Please note that this bit requires a minimum thickness of 3mm for the compression feature to work. With stop ring (for use with the Zund ARC system and IECHO…

SKU: csrc5622a
Category: , , ,

Description

Multielement multilayered “rainbow” coated, “Super” carbide, polished, compression (both up and down flute) router bit with a 6mm cutting edge diameter and max milling depth of 22mm. Please note that this bit requires a minimum thickness of 3mm for the compression feature to work. With stop ring (for use with the Zund ARC system and IECHO Tool Changer).

Additional information

Machine Model

Colex, Gerber, IECHO, Kongsberg, Multicam, Summa, Zund
Process Category

Router bits
Process Type

Route – Compression
Flutes

2 Flutes
Cut Angle

Compression Cut
Routing Diameter

6 mm
Max Cut Length

22
Shank Diameter

6 mm
Length Overall

60
Max Rpm

40000
Board – Rigid

ACM, Acrylic, Alucobond, Dibond®, Dilite, E-Panel®, EVA – Ethylene Vinyl Acetate, Expanded PVC, Gatorfoam®, Gatorplast®, HDU – High Density Urethane, IGEPA Bond Premium, IGPA, Komatex®, Max Metal®, Plaskolite®, Polycarbonate Board, Polyethylene 4 lbs., Precision Board®, Reynobond, Sign Foam®, Sintra®, Ultra Board®
Wood

Balsa, Birch Plywood, MDF, Poplar
Material Group

Board – Rigid, Wood
